The Deseeding Machine Manufacturer!
Anyang General International Co., Ltd. is an exporter and service provider with over 20 years of foreign trade experience, specializing in food processing machinery and complete equipment.
-
![Cherry Seed Remover Machine]()
Cherry Seed Remover MachineAGICO's cherry seed remover machine is a highly efficient automated device designed specifically for fruit and vegetable processing plants, jam factories, frozen fruit production lines, and juice...
-
![Olive Seed Remover Machine]()
Olive Seed Remover MachineAGICO olive seed remover machine efficiently separates olive pits from flesh with minimal damage. Designed for integration into automated processing lines, it ensures high output and consistent...
Broad market reach
AGICO has over 300 professional employees across various positions, providing a wide range of food processing machinery, technical expertise, machine design, installation and commissioning, and employee training services to over 150 countries across Europe, the Middle East, Africa, South America, Central Asia, and Southeast Asia.
Production Equipment
We produce a wide range of fruit and vegetable processing equipment, including washing, cutting, juicing, drying, and packaging machines, which can be used independently or as part of complete production lines.
One-stop service
AGICO provides one-stop integrated services and turnkey solutions for food processing machinery, saving procurement time and effort and reducing costs.
|
Model |
AGICO-120 |
AGICO-190 |
|
Voltage (V) |
380/220 |
380/220 |
|
Power (kw) |
1.5 |
2.2 |
|
Capacity (pcs/h) |
24000 |
72000 |
|
Denucleation Rate (%) |
98 |
98 |
|
Dimension (mm) |
1250×1050×1000 |
2300×1320×1320 |
|
Weight (kg) |
350 |
520 |
|
Material |
304 stainless steel |
304 stainless steel |
|
Plate Thickness (mm) |
2.0 |
2.0 |
|
Processing Specifications |
16-25 holes |
16-25 holes |
Features
Efficiency:
This device can quickly and effectively complete the process of removing seeds , saving a lot of time and labor costs compared to manual operations.
Precision:
This machine is manufactured using advanced technology and high-quality materials, which can ensure the accuracy and precision of seed removal and chopping.
Safety:
The structure and operation method of the equipment are very safe and reliable, and operators can operate without being injured.
Easy maintenance:
The equipment has a simple structure, is easy to disassemble, clean, and maintain, and has a long service life.
Feeding: Can indeed be fed into the hopper by hoist or even manually.
Crushing device: The crushing chamber has been configured on the top of the grenade machine as well as the two-layer structure can indeed be adequate to crush. The crushing roller of the crushing machine is made from stainless steel as well as the difference between the two rollers can be modified from 22 to 30 mm.
Separation device: The framework comprises a separating shaft, a separating screen as well as a transmission system. The separating shaft is equipped with a spirally disbursed separating blade; the separating rotating screen is developed by the punching of a stainless-steel plate as well as its role is to separate the peel and even the fruit seeds; the transmission system is situated at the front end of the decelerating frequency control frame, via the sprocket set Drive the separating shaft as well as separate the rotating screen.
Rack: The frame is the supporting aspect of the various parts of the coupling device, which are all made of high-quality stainless steel.
Electrical control cabinets: It is built from cabinets, electrical components, frequency converters, and so on, utilized to control the supply, the opening and closing of the engine of the crushing as well as separating devices, and the adjustment of the motor speed.
The process of extracting pomegranate seeds
The pomegranate enters the upper crushing device from the feed hopper, and the whole pomegranate is squeezed and cut into several small pieces after the relative squeezing of the crushing roller and the sharp pressure of the blade on the roller;
The crushing roller of the upper crushing device is made of stainless steel, and the gap between the two rollers can be adjusted to 20~30mm;
Then enter the lower crushing device for the second crushing. The lower crushing roller is made of non-toxic and highly elastic rubber, which will cause less damage to the pomegranate seeds. The gap between the two rollers can be adjusted by 10-20mm;
The pomegranate seeds and part of the juice leak out from the sieve, and enter the next process through the discharge port (transported to the juicer or other by the screw pump) and the pomegranate peel is discharged from the tail of the equipment.
Packing Details
|
Packing Details |
1.The machine will be coated with film firstly. |
|
2.Packed the machine with free-fumigation wooden case. |
|
|
Shipping Information |
3.Deliver the machines after the deposit. Shipped by container. |
|
4.Provide the complete documents that customs clearance required. |
FAQ
We are one of the most reliable deseeding machine manufacturers and suppliers in China, specialized in providing high quality custom service. We warmly welcome you to buy high-grade deseeding machine for sale here from our factory. For price consultation, contact us.
